The Computer
DOORS TO LATCH DCF?
the Door Close Function on the selected doors continuously as long as a door opening command
is absent.
INV. DOOR CLOSE LIMIT?
that require inverted door close limit input logic (DCL and/or DCLR). When this option is set,
the DCL and/or DCLR inputs must be active when the doors are closed and inactive when the
doors are open.
FIRE PH2. WITH DOORS CLOSED? Yes/No
set to Yes, a car recalled on Fire Phase 1 is allowed to enter Fire Phase 2 with doors closed.

Timer Menu Options

SHORT DOOR TIMER
doors will stay open after being reopened by the Photo Eye, Safety Edge or Door Open button.
CAR CALL DOOR TIMER
doors will stay open when the car stops to answer a car call.
HALL CALL DOOR TIMER
doors will stay open when the car stops to answer a hall call.
LOBBY DOOR TIMER
will stay open when the car stops to answer either a hall call or a car call at the Lobby Floor. The
location of the Lobby Floor is programmable
NUDGING TIMER (Range: 10-240 Seconds)
selected. Door Nudging Operation will begin when Nudging Timer elapses. Nudging Timer will
start when regular door timer elapses. This timer also determines the ON and OFF cycle time
for the NUDG output.
TIME OUT OF SERVICE TIMER (Range: 15-240 Seconds, or None)
take a car out of service when it is held at a floor excessively and calls are registered at other
floors. Timer starts when a call is registered at another floor. If timer expires before the car
closes its doors and begins to move, the car will be placed out of service. Typically, this occurs
when doors are held open by continuous activation of photo eye, a call button, or another
reopening device. When NONE is selected, no Time Out of Service timing is performed.
When the timer expires, the Timed Out of Service Indicator on the HC-MPU board will turn
ON. The controller will ignore the PHE (Photo Eye) input if the Stuck Photo Eye Protection
option is selected. In duplex or group installations, hall calls assigned to the car will be assigned
to another car. When the car closes its doors and begins to move again, it will return to Normal
service.
MOTOR LIMIT TIMER
troller attempts to move the car in the up direction and is reset when the car reaches its destina-
tion floor. If the timer expires before the car reaches its destination, the controller stops trying
to move the car up, to protect the motor. The car will then lower to the bottom floor and shut-
down. The Motor/Valve Limit Timer Indicator on the HC-MPU board will turn ON.
5-26 Manual # 42-02-1P21
FRONT/REAR/BOTH/NONE - This option would maintain
NONE/ FRONT/ REAR/ BOTH - Set this option for doors
(Range: 0.5-120.0 Seconds) - This is the length of time the
(Range: 0.5-120.0 Seconds) - This is the length of time the
(Range: 0.5-120.0 Seconds) - This is the length of time the
(Range: 0.5-120.0 Seconds) - This is the length of time the doors
(see "NUDGING?" on page
(Range: 1.0 - 6.0 Minutes) - This timer starts whenever the con-
FULLY MANUAL DOORS ONLY: If
(see "LOBBY FLOOR" on page
Used only if the Nudging option is
5-22)
5-19).
Used to
