User Interface
Table 4.13 MPI-B Diagnostics
Address
Port B inputs:
01 = (n/a)
02 = (n/a)
03 = (n/a)
04 = (n/a)
05 = UETS
06 = DETS
07 = (n/a)
101 08 = (n/a)
09 = EGOK
10 = RGR1
11 = RGR2
12 = RGOK
13 = (n/a)
14 = EB RST
15 = EBPS
16 = (n/a)
102 Port C inputs: (n/a)
103 Port D inputs: (n/a)
Port E inputs:
01 = SW1-1
02 = SW1-2
03 = SW1-3
04 = SW1-4
05 = (n/a)
06 = (n/a)
07 = (n/a)
104 08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
105 Port F inputs: (n/a)
106 Port G inputs: (n/a)
