Motion 4000

F3: System Mode

System mode allows the user to change certain system-wide options that do not require the car
to be on Inspection. To enter System mode:
• Move the F3 switch to the up position (all others down).
• Press N to select the desired System Mode item.
• Building Security Menu (see
• Passcode Request Menu (see
• Load Weigher Thresholds (see
• Analog Load Weigher Learn Function (see
• Controller System Menu - real time speed and position indication (see

Building Security Menu

Elevator Security is used to limit access to specified floors to passengers with a valid security
code. The Security code for each floor is a sequence of button presses on the car operating panel
and may consist of from one to eight "characters". Any floor with a programmed security code is
a secured floor when Security is ON. Security is turned ON or OFF by the controller Building
Security Input (BSI) in combination with the Master Software Key parameter in the Extra Fea-
tures Menu (Program mode). There are three possible settings for the Master Software Key:
ACTIVATED, ENABLED, and DEACTIVATED:
• If set to ACTIVATED, Security is ON.
• If set to ENABLED, Security is ON when the BSI input is turned ON.
• If set to DEACTIVATED, Security is OFF regardless of the status of BSI.
To find the BSI input, refer to the job prints. When Security is ON, car calls are registered only if
the call is not to a secured floor or the call is to a secured floor and the security code is correctly
entered within 10 seconds.
page 4-53)
page 4-56)
page 4-57)
page 4-57)
F3: System Mode
page 4-49)
4-53
4
