User Interface
Table 4.7 Spare Outputs Menu Options
702-709 Front Down Hall Call indicators. Typically used for hall gongs or chimes and activated as
the elevator levels into the associated landing. See drawings package. Do not use if a ded-
icated HC-UIO board is used for Hall Call Indicators.
702R-709R Rear Down Hall Call indicators. Typically used for hall gongs or chimes and activated as the
elevator levels into the associated landing. See drawings package. Do not use if a dedi-
cated HC-UIO board is used for Hall Call Indicators.
801-808 Front Up Hall Call indicators. Typically used for hall gongs or chimes and activated as the
elevator levels into the associated landing. See drawings package. Do not use if a dedi-
cated HC-UIO board is used for Hall Call Indicators.
801R-808R Rear Up Hall Call indicators. Typically used for hall gongs or chimes and activated as the
elevator levels into the associated landing. See drawings package. Do not use if a dedi-
cated HC-UIO board is used for Hall Call Indicators.
900 Audible Car Call Registered Output - Generated by registration of a car call. Used to comply
with specific handicap (barrier-free) codes that require an audible acknowledgment of car
call registration.
ABZ Attendant Service Buzzer Output - Generated momentarily when a hall call button is
pushed while the elevator is on attendant operation. Used for an in-car buzzer to alert the
attendant.
BOTTOM Bottom landing output. Activates when the car reaches the bottom landing. Used to facili-
tate load weigher calibration if needed.
CCDE Car Call Disconnect Enable Output - Comes on when car calls are canceled during photo-
eye anti-nuisance operation.
CCT Car Call Time Flag Output - Represents the state of the CCT flag. Activated when a car call
is canceled and deactivated when the door dwell time elapses (or is canceled by pressing a
car call or door close button).
CD Car Done Returning on Emergency Power Output - Active when the car has finished return-
ing on emergency power or when it is determined that the car cannot return.
CEPR Complete Emergency Power Return. Generated when the car has completed emergency
power return to the recall landing and is parked with doors open.
CFLT CSA FAULT OUTPUT - On when there is a CSA Redundancy fault condition (CNP, ILO and
UDF only). Used for Canadian Standards Association (CSA) code. If applicable, refer to the
job Compliance Report.
CGED Car Gong Enable Down Output - Generated to activate the in-car gong/lantern (front
doors). Activated (usually a double ding: on-off-on) to announce intention to move down
after the doors start to open. This will happen when a down hall call front has been entered
and the car has reached the floor the call originated from or if the doors are open and a car
call front is entered for a floor below.
CGEDR CGED for rear doors Output - Same as CGED but for the rear gong/lantern.
CGEU Car Gong Enable Up Output - Generated to activate the in-car gong/lantern (front doors).
Activated (usually a single-ding) to announce intention to move up after the doors start to
open. This will happen when an up hall call front has been entered and the car has reached
the floor the call originated from, or if the doors are open and a car call front is entered for
a floor above.
CGEUR CGEU for rear doors Output - Same as CGEU but for the rear gong/lantern.
CGF Computer Generated Fault Output - Comes on for any computer generated fault.
CHBPO Car and Hoistway Bypass Output - Active when a door is being bypassed (car gate or hoist-
way door for both the front and rear sides).
CR01-CR8 Car Card Reader Outputs, front landings. Indicates the associated card reader input has
been activated (allowing car call registration to this front landing). Once the call is regis-
tered, output will remain active until call completed.
4-36 Manual # 42-02-2P24
Spare Outputs Menu Options
