Speed and current curves
The values below are typical values and made with a nominal power supply of 24V DC and an ambient
temperature of 20˚ C.
LA37 current vs. load (start)
20.00
18.00
16.00
14.00
12.00
10.00
8.00
6.00
4.00
2.00
0.00
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
LA37 current vs. load (operation)
14.00
12.00
10.00
8.00
6.00
4.00
2.00
0.00
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
LA37 speed vs. load
4.00
3.50
3.00
2.50
2.00
1.50
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
-30 C
20 C
70 C
Load kN
-30 C
20 C
70 C
Load kN
70 C
20 C
-30 C
Load kN
Page 68 of 80
LA37, 20 C
LA37, 70 C
LA37, -30C
LA37, 20 C
LA37, 70 C
LA37, -30C
LA37, 20 C
LA37, 70 C
LA37, -30C
