System combination possibilities for LA37 IC Advanced
RF receiver
Type:
RF receiver
TXP transmitter
EVO transmitter
HB40
DP
Standard TECHLINE signal cables
*For more information, please go to www.linakthirdparty.com
TECHLINE signal cables
Plug types
Article No.
Flying
0367049-1500
leads*
Flying
0367049-5000
leads*
* The cable comes with an AMP connector that can be removed for flying leads
LA37 IC
HB40
EU Market (868.3MHz)
TR-TVPLRX868A02*
TR-TVTXP868A02*
TR-TVEVO868N03*
Material # Wires
PVC
6
PVC
6
Page 57 of 80
DP
Article No.
US market (916 MHz)
HB4X051-01
DP042-00
See the table below
Size
Colour
20AWG
Black
20AWG
Black
Signal cable
TR-TVPLRX916A02*
TR-TVTXP916A02*
TR-TVEVO916S03*
Length
Cable
(mm)
type
1500
Straight
5000
Straight
