Actuator with endstop signals and absolute positioning - PWM
I/O specifications:
Input/Output
Description
Brown
Blue
Red
Black
Green
Yellow
Violet
White
Specification
The actuator can be equipped with elec-
tronic circuit that gives an analogue feed-
back signal when the actuator moves.
See connection diagram,
fig. 10, page 34
12 or 24VDC (+/-)
12V ± 20%
24V ± 10%
Under normal conditions:
12V, max. 26A depending on load
24V, max. 13A depending on load
Signal power supply (+)
12-24VDC
Signal power supply GND (-)
Endstop signal out
Endstop signal in
Digital output feedback (PNP)
10-90% (Option 5)
20-80% (Option 6)
Not to be connected
Comments
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Current consumption:
Max. 60mA, also when the actuator is
not running
Output voltage min. V
Source current max. 100mA
NOT potential free
Output voltage min. V
Tolerances +/- 2%
Max. current output: 12mA
Frequency: 75Hz
It is recommendable to have the
actuator to activate its limit switches
on a regular basis, to ensure more
precise positioning
Page 34 of 80
- 2V
IN
- 2V
IN
