Actuator with CAN bus:
I/O specifications:
Input/Output
Description
Brown
Blue
Red
Black
Green
Yellow
* J1939-15 refers to Twisted Pair and Shielded cables. The standard/default cables delivered with LA37 CAN
do not comply with this.
Specification
Compatible with the SAE J1939 stand-
ard. Uses CAN messages to command
movement, setting parameters and to
deliver feedback from the actuator.
See the LINAK CAN bus user manual.
Actuator identification is provided, using
standard J1939 address claim or fixed
addresses.
See connection diagram,
fig. 14, page 58
12-24VDC + (VCC)
Connect Brown to positive
12V ± 20%
24V ± 10%
12V, current limit 25A
24V, current limit 13A
12-24VDC - (GND)
Connect Blue to negative
Extends the actuator
Retracts the actuator
CAN_L
CAN_H
Page 55 of 80
Comments
M
H-Bridge
Note: Do not swap the power
supply polarity on the brown and
blue wires!
Power supply GND (-) is electri-
cally connected to the housing
Current limit levels can be adjusted
through BusLink
If the temperature drops below
0°C, all current limits will
automatically increase to 30A
On/off voltages:
> 67% of V IN = ON
< 33% of V IN = OFF
LA37 with CAN bus does not
contain the 120Ω terminal
resistor. The physical layer is in
accordance with J1939-15.*
Speed:Baudrate: 250 kbps
Max bus length: 40 meters
Max stub length: 3 meters
Max node count: 10
(can be extended to 30 under
certain circumstances)
Wiring: Unshielded twisted pair
Cable impedance: 120 Ω (±10%)
