Actuator with IC Basic
I/O specifications:
Input/Output
Violet
White
Specification
Analogue feedback
0-10V
(Option 7.2)
Single Hall output (PNP) (Option 7.1)
Movement per Single Hall pulse:
LA371C: Actuator = 0.1372 mm per count
Frequency:
Frequency is 14-26 Hz on Single Hall
output depending on load.
Overvoltage on the motor can result in
shorter pulses
Signal GND
Comments
Standby power consumption:
12V, 60mA
24V, 45 mA
Ripple max. 200mV
Transaction delay 20ms
Linear feedback 0.5%
Max. current output: 1mA
It is recommendable to have the
actuator to activate its limit switches
on a regular basis, to ensure more
precise positioning
Output voltage min. V
Max. current output: 12mA
Max. 680nF
For correct wiring of power GND and
Signal GND see page 42
Page 37 of 80
- 2V
