Mounting guidelines - Trunnion mounted

The pinion mounting on the solar panel must:

• be of a good workmanship

• have smooth surfaces that do not wear or rasp the aluminium trunion pins on the actuator

• be of materials that are able to function with aluminium, also in respect of corrosion

• have dimensions that allow the actuator to move freely and without any sideload

• It is not allowed to apply any sideload on the actuator

• It is not allowed to overload the actuator. Be aware of extra loads that may be caused by for example

wind, snow, service, personnel, animals

• Always ensure that the actuator is supplied with the specified voltage, also at maximum current
