Feedback configurations available for IC Basic, IC Advanced and Parallel

Pre-config-
ured
None
PWM 10 – 90 %
Feedback 75 Hz
Single Hall* N/A
Analogue 0 - 10V
Feedback
Voltage
(AFV)*
Analogue 4 - 20mA
Feedback
Current (AFC)
Endstop At physical end
signal in/ stops.
out** Default for IC
Advanced.
All feedback configurations are available for IC Advanced.
* IC Basic feedback configurations available: Single Hall and 0-10V
** Parallel feedback configurations available: EOS
Customised Pros
range
N/A
0 – 100 % Suitable for long
75 – 150 Hz distance transmission.
Effectual immunity to
electrical noise.
N/A Suitable for long
distance transmission.
Any High resolution.
combination, Traditional type of
going negative feedback suitable for
or positive. most PLCs.
E.g. 8.5 – 2.2V Easy faultfinding.
over a full
Independent on stroke
stroke.
length, compared to a
traditional mechanical
potentiometer.
Any High resolution. Better
combination, immunity to long cables
going negative and differences in
or positive. potentials than AFV.
E.g. 5.5 – 18mA Provides inherent error
over a full condition detection.
stroke.
Independent on stroke
length, compared to a
traditional mechanical
potentiometer.
Any position. Can be set at any
position over the full
stroke length.
Page 43 of 80
Cons
N/A
More complex
processing required,
compared to AFV and
AFC.
No position indication.
Not recommended
for applications with
long distance cables or
environments exposed
to electrical noise.
Not suitable for signal
isolation.
Only one endstop can
be customised.
