Actuator with absolute positioning - Analogue feedback
I/O specifications:
Input/Output
Description
Brown
Blue
Red
Black
Green
Yellow
Violet
White
Specification
The actuator can be equipped with elec-
tronic circuit that gives an analogue feed-
back signal when the actuator moves.
See connection diagram,
fig. 7, page 28
12 or 24VDC (+/-)
12V ± 20%
24V ± 10%
Under normal conditions:
12V, max. 26A depending on load
24V, max. 13A depending on load
Signal power supply (+)
12-24VDC
Signal power supply GND (-)
Not to be connected
Not to be connected
Analogue feedback
0-10V
(Option B)
0.5-4.5V (Option C)
Not to be connected
Comments
To extend actuator:
Connect Brown to positive
To retract actuator:
Connect Brown to negative
To extend actuator:
Connect Blue to negative
To retract actuator:
Connect Blue to positive
Current consumption:
Max. 60mA, also when the actuator is
not running
Tolerances +/- 0.2V
Max. current output: 1mA
Ripple max. 200mV
Transaction delay 100ms
Linear feedback 0.5%
It is recommendable to have the
actuator to activate its limit switches
on a regular basis, to ensure more
precise positioning
Page 28 of 80
