Chapter 4

Specifications

Motor:
Cable:
Brake:
Hand crank:
Housing:
Spindle part:
Temperature range:
End play:
Weather protection:

Usage:

• Duty cycle is max. 10%
• Performance of LA37 with Modbus is limited to 10kN.
• Storage temperature: -55
• Noise level: 73 dB (A) measuring method DS/EN ISO 8746 actuator not loaded
• Safety device regarding functional failure:
Mechanical endstop
LA37 is equipped with mechanical endstop
* Modbus actuators only 24V - please see the Modbus installation guide:
http://www.linak.com/techline/?id3=2363
** Special control cabels for the Modbus actuator - please see the Modbus installation guide:
http://www.linak.com/techline/?id3=2363
Permanent magnet motor 12 or 24V *
Motor: 2 x 14 AWG PVC cable
Control: 6 x 20 AWG PVC cable **
Integrated brake ensures a high self-locking ability. The brake is deactivated when
the actuator is powered to obtain a high efficiency
As a standard feature the actuator can be operated manually
The housing is made of casted aluminium, coated for outdoor use and in harsh
conditions
Outer tube: Extruded aluminium anodised
Inner tube: Stainless steel AISI304/SS2333
Acme spindle: Trapezoidal spindle with high efficiency
- 30 C to +70 C
o o
- 22 F to +158 F
o o
Full performance +5 C to +40
o
2 mm maximum
Rated IP66 for outdoor use. Furthermore, the actuator can be washed down with a
high-pressure cleaner (IP69K)
C to +105 C
o o
Page 63 of 80
