Overview
Sensor data from
IDS sensors
8
 facilitate to assign a sensor to a measured parameter with differently colored
couplings
 have quick-lock couplings with which to fix the sensors to the meter.
Information on available IDS sensors is given on the Internet.
IDS sensors transmit the following sensor data to the meter:
 SENSOR ID
– Sensor name
– Sensor serial number
 Calibration data
 Measurement settings
The calibration data are updated in the IDS sensor after each calibration proce-
dure. A message is displayed while the data are being updated in the sensor.
In the measured value display, you can display the sensor name
and serial number of the selected sensor with the [Info] softkey. You
can then display further sensor data stored in the sensor with the
[More] softkey (see section 4.1.6 S

1.2.2 Wireless operation of IDS sensors

With the aid of the adapters in the IDS WLM System, IDS sensors with plug
head connectors (variant W) can be wirelessly connected to your
Multi 9620 IDS.
Two adapters, one at the IDS meter (IDS WA-M) and one at the sensor (IDS
WA-S), replace the sensor cable with an energy-saving Bluetooth LE radio
connection.
Further information on the wireless operation of IDS sensors:
 Web resources
 Operating manual of the IDS WLM System.

1.2.3 IDS adapter for analog sensors

With the aid of an IDS adapter, you can also operate analog sensors
on the Multi 9620 IDS. The combination of the IDS adapter and analog sensor
behaves
like an IDS sensor.
The following IDS adapters can be operated on the Multi 9620 IDS:
®
inoLab Multi 9620 IDS
, page 17).
ENSOR INFO
ba77173e04 12/2017
