Troubleshooting

General
Problem
Drive unit does not start
Drive unit lacks power
Drive unit suddenly stops
Possible causes
No battery in the drive unit
Battery is discharged
Battery is defect
If the drive unit is defect (e.g. short-
circuited) do not insert a battery as
this will blow the internal fuse and
cause damage to the battery.
If the UBCII had indicated that the
battery was in working condition
(green LED illuminating) this indi-
cates that the drive unit is defective
and the damage was not caused by
the battery.
Drive unit did not cool down after
sterilization
Mode switch is set to «lock» (off
position)
No electrical contact between drive
unit and battery casing
Battery is not fully charged or past
life cycle
Wrong attachment used (e.g. drill-
ing speed vs. reaming speed)
Drive unit has not been properly
serviced
Attachments have not been prop-
erly serviced
Drive unit has overheated
Battery is empty/discharged
If the drive unit is defect (e.g. short-
circuited) do not insert a battery as
this will blow the internal fuse and
cause damage to the battery. If the
UBCII had indicated that the battery
was in working condition (green LED
illuminating) this indicates that the
drive unit is defective and the dam-
age was not caused by the battery.
Battery Power Line II Surgical Technique DePuy Synthes
Solution
Insert charged battery
Charge or replace battery
Replace battery
Send drive unit and battery to
Synthes Service Center
Allow to cool to room temperature
Set mode switch to ON/FWD/REV
Reinsert or change battery casing
Charge or replace battery
Change attachment
Send drive unit to Synthes Service
Center
Send attachments to Synthes
Service Center
Allow to cool to room temperature
Charge or replace battery
Send drive unit to Synthes Service
Center
