Operating Instructions
Battery Pack
(battery casing with inserted battery)
Circulating person
Insert the non-sterile battery through the sterile cover
into the battery casing (Fig. 5a). Press down on the bat-
tery to ensure it is fully seated (Fig. 5b).
Note:
The shape of the battery ensures that it is in-
serted with the correct pole alignment. The circulat-
ing person must not touch the outside of the battery
casing.
Remove the sterile cover from the battery casing (Fig. 6).
Precaution:
Avoid all contact with the outside of the
battery casing in order not to contaminate it. Should
the non-sterile battery or the circulating person's
hand come into contact with the outside of the bat-
tery casing, it must be cleaned and resterilized be-
fore being used in the operating room.
16
DePuy Synthes Battery Power Line II Surgical Technique
Figure 5a
Figure 5b
Figure 6
Circulating
person
Scrubbed person
Circulating
person
Scrubbed person
Circulating
person
Scrubbed person
