Operating Instructions
Battery Oscillator II (530.710)
To operate the drive unit, turn the mode switch to the
"ON" position.
The single variable-speed trigger allows control of the
oscillating frequency from 0 to 12 000 oscillations per
minute. When the trigger is released, the power tool
stops immediately. Ensure the drive unit is running prior
to contacting the bone. Optimal sawing performance is
achieved by gently moving back and forth in the plane
of the saw blade, allowing the blade to oscillate freely
slightly beyond the bone.
Precaution: To prevent injuries, the mode switch of
the drive unit should always be in the off position
when inserting or removing saw blades, or adjusting
the sawing plane.
For further information on the System Specifi cations and
Duty Cycle, please refer to page 76f.
Locked symbol
Drive unit is off for safety
Battery Power Line II Surgical Technique DePuy Synthes
ON
Drive unit is on for sawing
