Trinkle Quick Coupling (530.794), Drill speed
Trinkle Quick Coupling (530.784), Ream speed
Accepts cutting tools and instruments with a Trinkle
fi tting.
Trinkle QC XXL, modified (530.795), Ream speed
Accepts cutting tools and instruments with a large,
tapered, modifi ed Trinkle fi tting.
Insert instrument
Pull back the collar of the attachment and insert the
instrument, turning it slightly to align the instrument
(Fig. 1).
Release the collar, pulling lightly on the instrument to
ensure it is secure.
Remove instrument
Pull back the collar of the attachment and remove the
instrument (Fig. 1).
Figure 1
Battery Power Line II Surgical Technique DePuy Synthes
11
