8. Load Synthes Washing Basket

Please use the specially designed tray for machine wash-
ing as supplied by Synthes (68.001.620, 68.001.625).
Follow the numbered loading plans as shown on
pages 54 and 55. Ensure that the attachments are posi-
tioned in an upright position as shown and fully opened.
This will ensure that the water can flow off any surfaces.
Damage due to improper reprocessing is not covered by
the warranty.
Notes:
• A lid (68.001.602, 68.001.604) is available for the
washing basket. This can be used for sterilization,
but is not required for machine washing.
• Do not wash the system in the Synthes Vario Case
(689.202).
• Loading Plan for Washing Basket Full Size
Washing Basket (68.001.620) with
Lid for Washing Basket (68.001.602) for BPL II
Dimensions (Length × Width × Height):
Washing Basket without Lid:
Washing Basket with Lid:
• Loading Plan for Washing Basket size ½
Washing Basket (68.001.625) with
Lid for Washing Basket (68.001.604) for BPL II
Dimensions (Length × Width × Height):
Washing Basket without Lid:
Washing Basket with Lid:
⁄
1
1
500 × 250 × 119 mm
504 × 250 × 150 mm
252 × 250 × 119 mm
256 × 250 × 150 mm
Battery Power Line II Surgical Technique DePuy Synthes 51
