Operating Instructions
Battery Reciprocator II (530.715)
To operate the drive unit, turn the mode switch to the
"ON" position.
The single variable-speed trigger allows control of the
reciprocating frequency from 0 to 14 000 oscillations per
minute. When the trigger is released, the tool stops
immediately. Ensure the drive unit is running prior to
contacting the bone. Optimal sawing performance is
achieved by gently moving back and forth in the plane
of the saw blade, allowing the saw blade to reciprocate
freely slightly beyond the bone.
Precaution: To prevent injuries, the mode switch of
the drive unit should always be in the off position
when inserting or removing saw blades, or adjusting
the sawing plane.
For further information on the System Specifi cations and
Duty Cycle, please refer to page 76f.
42 DePuy Synthes Battery Power Line II Surgical Technique
Locked symbol
Drive unit is off for safety
ON
Drive unit is of for sawing
