2.16.9 GE-LUNAR 8022 x-ray tube

Table 2-6. LUNAR 8022 X-ray tube technical information.
Nominal anode input power
Maximum anode heat content
Anode heating and cooling curves
Anode target material
Nominal focal spot values
Maximum useful voltage
Maximum filament current
This document contains confidential or proprietary information of GE-Lunar Corp. Neither the document nor the information therein is
to be reproduced, distributed, used or disclosed, either in whole or in part, except as specifically authorized by GE-Lunar Corp.
PRODIGY Service Manual (Rev C - 2000)
Figure 2-19. Reference axis and target angles for tube head assembly
Reference axis
Target angle
361 Watts
6000 Joules
Refer to figure 5.
Tungsten
Refer to figure 4.
78° (reference to nor-
mal)
0.5
95 kVp
2.2 Amperes
IEC 613/1989
IEC 613/1989
IEC 613/1989
IEC 601-2-28
IEC 601-2-28
IEC 601-2-28
IEC 336/1982
Not Applica-
ble
Not Applica-
ble
System Overview 2-85
