1.1.2 Internal Symbols

1.1.3 Labels

This document contains confidential or proprietary information of GE-Lunar Corp. Neither the document nor the information therein is
to be reproduced, distributed, used or disclosed, either in whole or in part, except as specifically authorized by GE-Lunar Corp.
1-16 Safety
Shutter Open: shows the location of the Shutter Open indicator.
X-ray On: shows the location of the X-Ray On indicator.
Type B Equipment: shows that the scanner has Type B
protection against electrical shock.
• The following symbols are found inside the PRODIGY, and in the Service
Manual.
Protective Earth: shows the location of a Protective Earth
Terminal.
Functional Earth: shows the location of a Functional Earth
Terminal.
• The following labels are found on the PRODIGY Scanner.
Laser Caution Label: Shows that the scanner uses
a Class II laser. This label is not found on systems
shipped to Canada.
Laser Caution Label: Canada only
PRODIGY Service Manual (Rev C - 2000)
