4 long_enable
5 /long_fwd
6 long_lsw_override
7 /collimator_open_ctrl
This document contains confidential or proprietary information of GE-Lunar Corp. Neither the document nor the information therein is
to be reproduced, distributed, used or disclosed, either in whole or in part, except as specifically authorized by GE-Lunar Corp.
PRODIGY Service Manual (Rev C - 2000)
R/W 0 Longitudinal motor enable – low blocks trans motor pulses and
forces Centent drive to standby current level.
R/W 0 Longitudinal motor direction control.
R/W 0 Longitudinal limit switch override – prevent limit switch contact
from blocking step pulses at hardware level
R/W 1 Collimator solenoid control.
System Overview 2-47
