Digital Signals
DPX-NT Service Manual (Rev A- 1999)
Individual Detector Signals (Stored in DMB Flash RAM)
• GAIN - combination of Peak and AGS signal gain - setting for Shaping
Amplifier - visible only with Oscilloscope
• AGS - AGS amplify or Attenuate signal - visible only with Oscilloscope
• BiPolar - Bipolar signal out of the shaping Amplifier
• AGS ROLL - logic signal for AGS rollover - this signal is not currently
utilized by the software
• LE - Low Energy Event detected and counted
• HE - High Energy Event detected and counted
• SAMPLE - Sample clock signal
• AGS ENABLE - Operate Calibrate signal - locks out AGS for Peaking
operation
Troubleshooting 4-151
