22.Then move the arm all the way down to the foot end of the scan table. At
this time make sure that the Lower cable bundle and the high voltage cable
bundle have some slack where the cables enter the cable track near the
bulkhead area. Then make sure the cable track has at least 1/8" of clearance
from hitting the frame. To adjust this slide the cable track in the trough it rides
in to get the proper clearance, then tighten the screw that holds the cable
track in place with a 1/8" hex wrench and a 3/8" wrench. Move the arm up and
down the scan table to be sure there is nothing wrong with the cable track
motion. Leave the arm at the foot end of the table.
23.Leave a little slack in the cables from the cable track to the pan area to
allow all of the cables to be routed and wire tied exactly like the original
cables.
24.Reconnect the A/C power cord, put the table top, pad, and end panels
back on the scanner.
25.Turn on the scan table, computer, monitor and printer. Perform required
tests per section 6.9 of the Prodigy Service Manual.
5.4

Upper Cable Bundle Replacement

Tools Necessary:

5.4.1 Procedure

1. Turn off the power to the scan table.
2. Remove the table top by removing the two screws at each end.
3. Remove the front panel of the scan table
4. Lastly, remove the column cover of the arm held in place by screws.
5. Remove the upper and lower arm covers by removing the (8) screws that
hold it in place.
6.Open the cable track and cut the wire ties at the end of it. Disconnect all the
cables coming from the cable track and remove the cable bundle as far as the
top of the column (through the hole).
5-160Service Procedures
• Small Phillips Screwdriver
• Small Slot Screwdriver
• Diagonal Cutters
• Hex Wrench Set
• Mini Molex Pin Extractor
• Large and Small Wire Ties.
PRODIGY Service Manual (Rev B - 1998)
