2.14 Audible X-RAY OFF Signal

This document contains confidential or proprietary information of GE-Lunar Corp. Neither the document nor the information therein is
to be reproduced, distributed, used or disclosed, either in whole or in part, except as specifically authorized by GE-Lunar Corp.
PRODIGY Service Manual (Rev C - 2000)
• An audible signal notifies the operator that there is a "safe" condition
when the Shutter is closed.
• The FOINK or cSBC board senses the closure of the Shutter or the
cessation of current through the X-ray Insert (+28VDC Power Supply or
Model 7861 HVPS) and switches on the audible signal if either of these
occur during an exposure.
