Introduction
Main components of the

control unit

56
1.2.2 Control unit
1
7
Fig. 1-2 Control unit (example with heating line for the permeate line)
1 Operating panel
2 Control electronics
3 Permeate valve (3/2 port valve)
4 Air compressor
5 Permeate suction tube (back)
6 Permeate line (front)
7 Permeate pump
2
6
PurCon IS
3
4
5
