Mounting the
temperature
measuring box
ba43133e06 05/2009
12 Feed cable end (pos. 6 in Fig. 3-9) of the temperature measur-
ing box through the cable gland to the terminal strip and con-
nect it there. The terminal assignment is shown in the following
Fig. 3-10.
Temperature
measuring box
Fig. 3-10 Terminal strip of the control unit
Glue the temperature measuring box to a suitable outside wall of the
control unit (cable downward). Make sure that no direct sun light, no
other heat sources or other environmental influences interfere with the
measurement of the ambient temperature. The temperature measuring
box has a hook and loop fastener with an adhesive film to be attached.
Pull off the adhesive film and tightly press the temperature measuring
box against the clean surface.
Heating line (option)
