PurCon IS
Types of mounting
Connecting the
permeate suction line
with the filter unit
ba43133e06 05/2009

3.2.2 Filter unit and permeate suction line

The filter unit can be mounted on site in the following ways:
Chain mounting with the PCIS-MSK accessory set
Pipe mounting with the PICS-MSS accessory set, e.g. on the railing
Note
Observe the minimum immersion depth of the filter unit (see dimensio-
nal drawing in chapter 7 T
rely immersed.
Note
Instructions for mounting are given in the mounting instructions of the
accessories. Ordering information for the accessories are given in sec-
tion 8 A
CCESSORIES AND CONSUMABLE MATERIALS
Fig. 3-2 Connecting the permeate suction line with the filter unit
1 Remove the coupling nut (pos. 1 in Fig. 3-2) and the threaded
plugs (pos. 2).
2 Push a hose clip (pos. 3) over the encasing tube (pos. 4).
3 Thread the two suction hoses (pos. 5) through the compressed
air connection (pos. 5).
4 Slip the encasing tube on the compressed air connection and
secure with the hose clip.
. The frame tube must be enti-
ECHNICAL DATA
4
3
5
6
2
1
Commissioning
.
63
