wtw PurCon IS sample preparation Operating Manual page 31

PurCon IS
Installation and
returning to service
ba43133e06 05/2009
2
Fig. 5-1 Removing the filter
7 Loosen the two knurled-head screws (pos. 2 in Fig. 5-1).
8 Swivel the retaining clip (pos. 3) to the side and tilt the filter box
down forwards.
9 Pull out the filter from the retaining clip.
Insert the filter in the filter unit in the reverse order to its removal and
immerse the filter unit in the sample. For details of how to start sample
preparation, see section 4.2 on page 74.
3
1
Maintenance
79
