Structure and function

PurCon IS consists of the following main components:

Filter unit

Control unit
1.2.1 Filter unit
Fig. 1-1 Filter unit
1 Framework
2 Filter
3 Air shower
4 Permeate suction pipeline
5 Suction tube
4
5
1
2
3
