  • Page 1 Energy efficiency module MSE6-E2M Description Mounting Installation Commissioning 8074159 2017-07c [8074161]...
  • Page 2 Essential or useful accessories Information on environmentally sound usage Text designations: • Activities that may be carried out in any order 1. Activities that should be carried out in the order stated – General lists Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 3: Table Of Contents

    ......... . Festo – MSE6-E2M-IN-EN – 2017-07c – English...
  • Page 4 ............... . Festo – MSE6-E2M-IN-EN – 2017-07c – English...
  • Page 5 Overview of the descriptions è Tab. 1. Conventions Chapter 7 describes the parameters and data of the MSE6-E2M. These appear on the operator unit CPX-MMI-1 in English. [..] The data and parameters in the text displayed in English on the operator unit are shown in square brackets in this description, e.g.

  • Page 6: Safety And Requirements For Product Use

    When the input pressure is being switched off (e.g. during a venting procedure), a resid­ ual pressure of P2  1 bar (P2  0,1 MPa) can remain at the output of the MSE6-E2M. • Use appropriate measures to ensure that the residual pressure does not result in a hazard.

  • Page 7: Foreseeable Misuse

    – For installation of the MSE6-E2M in front of a safety valve, it must be ensured, possibly through additional suitable measures, that this layout does not impair the intended operation of the safety valve and of the system.

  • Page 8: Range Of Application And Certifications

    (è Appendix A.1). The product-relevant EU directives can be found in the declaration of conformity. For certificates and the declaration of conformity for this product, please refer to è www.festo.com/sp. The product fulfils the requirements of EU directives and is marked with the CE marking. Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 9: Overview

    The module is typically assembled behind a service unit combination. The MSE6-E2M consists of the main components: shut-off valve, flow sensor, pressure sensor and bus node. The fieldbus interface allows complete integration into a higher-order controller, e.g. a system or machine controller.
  • Page 10 Creates the communicative connection to a higher-order con­ troller through a fieldbus, passes on the control signals to the integrated sensor module and monitors their functioning. System supply Electrical power supply of the device Tab. 2.1 Individual functions Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 11: Mode Of Operation

    This avoids additional air consumption through leakages. If production is to con­ tinue on the system, then it must be signaled to the MSE6-E2M. The shut-off valve opens and the sys­ tem is again supplied with compressed air.

  • Page 12: Commissioning, Diagnostics And Operational Functions

    The MSE6-E2M continuously records the flow, prepares the data and makes it available cyclically. To detect high flow rates, the MSE6-E2M offers the option of parameterising limit values for the flow. If the parameterised limit value is exceeded, then the device will output a diagnostic message.
  • Page 13 With fieldbuses that do not possess extensive diagnostic functions, the interface diagnostic information of the MSE6-E2M is available via the I/O diagnostic interface. The I/O diagnostic interface enables bus-independent access to diagnostic information, data and parameters via internal digital I/Os (16 inputs and 16 outputs).

  • Page 14: Mounting And Installation

    • Do not touch any components. • Observe the handling specifications for electrostatically sensitive devices. Note For the combination of the MSE6-E2M with MS6 modules, please observe the corres­ ponding mounting instructions (è Chapter 3.3). Pay particular attention to the following: •...

  • Page 15: Mounting

    Note Fasten the MSE6-E2M with screws of size M6 and use washers, if required. The MSE6-E2M is intended for mounting on the wall. The mounting brackets are integrated and contain drill holes for wall mounting. 1. Ensure that the compressed air supply, as well as the operation and load/actuator supply, are switched off.
  • Page 16 MSE6-E2M Type Connection technology CPX-FB13 Depending on the bus node, additional space for the con­ nection technology is required for mounting. CPX-FB33 CPX-FB34 CPX-FB35 CPX-FB36 CPX-FB37 Type MSE6-E2M Fig. 3.3 Dimension table [mm] Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 17: Combination With Ms6 Modules

    4. Connect the earth terminal on the left-hand pneumatic base plate with low impedance (short cable with large cross section) to the left end plate of the electrical interlinking module of the MSE6-E2M. Festo – MSE6-E2M-IN-EN – 2017-07c – English...
  • Page 18 • With low-impedance connections, make sure that the earth terminal at the left end plate of the electrical interlinking module on the MSE6-E2M and the earth terminal at the power supply connec­ tion have the same potential and that there are no compensating currents. If necessary, the pre- assembled electrical connection of the MSE6-E2M must be replaced by a longer, electrically equival­...

  • Page 19: Dismounting

    When the input pressure is being switched off (e.g. during a venting procedure), a resid­ ual pressure of P2  1 bar (P2  0,1 MPa) can remain at the output of the MSE6-E2M. • Use appropriate measures to ensure that the residual pressure does not result in a hazard.

  • Page 20: Installation

    When the input pressure is being switched off (e.g. during a venting procedure), a resid­ ual pressure of P2  1 bar (P2  0,1 MPa) can remain at the output of the MSE6-E2M. • Use appropriate measures to ensure that the residual pressure does not result in a hazard.

  • Page 21: Selecting The Power Supply Unit

    • Use regulated power supplies to ensure that the load voltage of the outputs always remains within the permitted tolerances during operation (è Chapter 3.5.4). • Make sure that the selected power supply units provide sufficient power. Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 22: Power Supply Of The Mse6-E2M

    Warning Risk of injury If the load or operating voltage of the MSE6-E2M is switched off, then the shut-off valve switches to the initial position (pressurise). If the valve was previously closed, the sys­ tem is pressurized. If the system was vented, pressurisation takes place suddenly.
  • Page 23 Tab. 3.1 Pin allocation, system supply Potential equalisation The MSE6-E2M has two earth terminals for potential equalisation: – Pin 4 (M18 plug connector) of the power supply connection of the system supply – Earth terminal on the left-hand end plate of the electrical interlinking module –...
  • Page 24 External fuses interlinking module. Separately switchable actuator technology System supply supply Fig. 3.6 Example – connecting a common 24 V power supply and the potential equalisation Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 25: Commissioning

    Warning Risk of injury If the load or operating voltage of the MSE6-E2M is switched off, then the shut-off valve switches to the initial position (pressurise). If the valve was previously closed, the sys­ tem is pressurised. If the system was vented, pressurisation takes place suddenly.

  • Page 26: Approach

    The individual commissioning steps are shown in the diagram below. Step 1 – Checking of the connected pneumatic application Step 2 – Commissioning on the fieldbus with testing of the address allocation Fig. 4.1 Commissioning steps (example at the bus node CPX-FB33) Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 27: Prior To Commissioning

    2. Check the electric cabling of the MSE6-E2M. 3. Check the DIL switch settings of your MSE6-E2M, if necessary. The characteristics of the MSE6-E2M can be adapted to various requirements. You can carry out important settings as follows: • through DIL switches directly at the bus node (information on this can be found in the brief description of the bus nodes è...

  • Page 28: Brief Instructions For Commissioning

    5. Activate the network scanner or open the hardware catalogue. 6. Transfer the MSE6-E2M and the bus node from the hardware catalogue into the controller software (detailed information on the topic can be found in the documentation for the higher-order controller).

  • Page 29: Options For Parameterisation

    Commissioning Options for parameterisation The parameterisation of the MSE6-E2M can be undertaken as follows, depending on the fieldbus pro­ tocol used: Interface module or network scanner/bus Network-specific configurators; parameters master; the desired parameterisation can be can be modified during the commissioning guaranteed, e.g.

  • Page 30: Measurement And Control Functions

    Measurement and control functions Measurement and control functions Information on the topic of measurement and control functions can be found in Chapter 5 of the system description for the energy efficiency module (è MSE6-E2M-SY-…). Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 31: Input/Output Data

    Input/output data Input/output data Overview The MSE6-E2M possesses multiple functional module data, which can be replaced with the higher-or­ der controller using the I/O data presented below. Data field for Input word Output word Flow measurement Em.0 – Consumption measurement –...

  • Page 32: Parameterisation

    Parameterisation Detailed information on parameterisation can be found in Chapter 7 of the system de­ scription for the energy efficiency module (è MSE6-E2M-SY-…). The following tables offer an overview of the module parameters of the function module. A distinction is made between “Changeable module parameters”...

  • Page 33: Diagnostics And Error Handling

    Chapter 8 of the system description for the energy efficiency module (è MSE6-E2M-SY-…). Summary of diagnostics options The MSE6-E2M offers comprehensive options for diagnostics and error handling. The following options are available (è also Tab. 8.1): On the spot diagnostics via LED...

  • Page 34: On The Spot Diagnostics Via Led

    On the spot diagnostics via LED Information on the topic of on-the-spot diagnostics can be found in Chapter 8.2 of the system description for the energy efficiency module (è MSE6-E2M-SY-…). Diagnosis via status bits or the I/O diagnostic interface Information on the topic of diagnostics through status bits or the I/O diagnostics inter­...

  • Page 35: Error Numbers

    Diagnostics and error handling Error numbers Possible errors of the MSE6-E2M are divided into three error classes with different priority, depending on the seriousness of the error. If an error occurs, the system error LED (SF LED) will flash depending on the error class.
  • Page 36 The following covers only module-specific errors. An overview of all possible error mes­ sages, incl. those of the bus nodes, can be found in Chapter 8 of the system description for the energy efficiency module (è MSE6-E2M-SY-…). The following errors can be reported: Error no.

  • Page 37: A Technical Appendix

    – Undervoltage diagnostic 15 … 17 message (trigger level without hysteresis) Pressure sensor – Pressure measuring range [bar] 0 … 14 [MPa] 0 … 1.4 – Accuracy [%FS] typ. ±3 – Repetition accuracy [%FS] ±0.3 Festo – MSE6-E2M-IN-EN – 2017-07c – English...
  • Page 38 5) %FS = percent of the measurement value range end value (fullscale) 6) Typical accuracy with nominal conditions (6 bar (0.6 MPa), 23 °C and horizontal mounting orientation) 7) Explanations of the severity levels è Tab. A.2. Tab. A.1 Technical Data Festo – MSE6-E2M-IN-EN – 2017-07c – English...
  • Page 39 Acceleration [m/s²] Duration [ms] Shocks per direction ±150 ±300 Continuous shock load Acceleration [m/s²] Duration [ms] Shocks per direction ±150 1000 Tab. A.2 Values for vibration and shock in accordance with IEC 60068 Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 40: Connecting Cable

    Also take into account here the distance and the fieldbus baud rate. Connecting cable Use a connecting cable with a sufficient cable cross-section. Avoid long distances between the power unit and the MSE6-E2M. Long cables reduce the voltage supplied by the power supply unit. Preparing the connecting cable Caution The position of the pins on the plug connector is different from that on the socket! –...
  • Page 41 4. Connect the ends of the conductors. 5. Replace the connecting part on the housing of the plug connector/socket. Pull the cable back so that there are no loops inside the housing. 6. Tighten the strain relief. Festo – MSE6-E2M-IN-EN – 2017-07c – English...

  • Page 42: B Glossary

    Dual-in-line switches consist of several switch elements with which settings can be made. Input I/O diagnostic interface The I/O diagnostic interface is a bus-independent diagnostic interface at I/O level that permits access to internal data of the MSE6-E2M. I/Os Inputs and outputs Output PLC/IPC...

  • Page 43: Index
