ADF7023 Evaluation Board Schematics and BOMs
Table 2 Components Common to All Daughter Boards
Qty Name
1 C1
9 C14, C16, C24, C28,
C30, C33, C37, C62,
C65
2 C15, C27
3 C23, C34, C35
1 C25
2 C26, C42
2 C39, C40
4 R3, R4, R8, R9
1 R12
1 R15
1 R16
1 Y1
1 Y2
1 U1
Table 3 Eval-ADF7023DB1Z Components (868/915MHz Separate Matches)
Qty Name
1 C2
2 C3, C5
1 C18
1 C19
1 C20
1 C66
Value Tolerance
1.5nF ±5%
220nF ±10%
100pF ±5%
18pF ±5%
150nF ±5%
10uF ±20%
5.6pF ±5%
DNI
36k ±1%
100k ±1%
1.1k ±1%
26MHz
32.768kHz
Value Tolerance PCB Decal
±0.25pF
1pF
±0.25pF
2.2pF
56pF ±5%
2.7pF ±0.25pF
1.2pF ±0.25pF
100pF ±5%
R e v 1 . 1 | Page 38
PCB Decal Manufacturing Part No.
0402 GRM155R71H152KA01D
0402 GRM155R61A224KE19D
0402 GRM1555C1H101JZ01D
0402 GRM1555C1H180JZ01D
0402 GRM155R61A154KE19D
0603 6R3R14X106MV4T
0402 GRM1555C1H5R6DZ01D
Not inserted
0402 MCR01MZPF3602
0402 MCR01MZPF1003
0402 MCR01MZPF1101
NX3225SA-26.000000MHZ-G2
ABS07-32.768KHZ-7-T
LFCSP-32 ADF7023
Manufacturing Part No.
0402 GRM1555C1H1R0CA01D
0402 GRM1555C1H2R2CZ01D
0402 GRM1555C1H470JZ01D
0402 GRM1555C1H2R7CZ01D
0402 GRM1555C1H1R2CZ01D
0402 GRM1555C1H101JZ01D
