2 C18, C67
1 C66
1 L1
1 L2
2 L3, L4
2 L5, L10
1 L6
Table 6 Eval-ADF7023DB4Z Components (433MHz Combined Match)
Qty Name
1 C2
1 C3, C22
2 C18, C67
1 C19
1 C20
1 C66
1 L1
1 L2, L9
1 L3
1 L4
1 L6
1 L7
270pF ±5%
100pF ±5%
15nH ±5%
82nH ±5%
27nH ±5%
33nH ±5%
100nH ±5%
Value Tolerance PCB Decal
DNI
3.9pF ±0.25pF
270pF ±5%
4.7pF ±0.1pF
2.7pF ±0.1pF
100pF ±5%
13nH ±5%
33nH ±5%
30nH ±5%
41nH ±5%
100nH ±5%
82nH ±5%
R e v 1 . 1 | Page 40
0402 GRM1555C1H271JA01D
0402 GRM1555C1H101JZ01D
0402 Coilcraft 0402CS-15NXJL
0402 Coilcraft 0402CS-82NXJL
0402 Coilcraft 0402CS-27NXJL
0402 Coilcraft 0402CS-11NXJL
0402 Coilcraft 0402CS-R10XJL
Manufacturing Part No.
Not Inserted
0402 GRM1555C1H3R9CZ01D
0402 GRM1555C1H271JA01D
0402 GRM1555C1H4R7BA01D
0402 GRM1555C1H2R7BA01D
0402 GRM1555C1H101JZ01D
0402 Coilcraft 0402CS-13NXJL
0402 Coilcraft 0402CS-33NXJL
0402 Coilcraft 0402CS-30NXJL
0402 Coilcraft 0402CS-41NXJL
0402 Coilcraft 0402CS-R10XJL
