Reading Interrupt Source on Receiver board
Once the Transmitter has transmitted a packet you should now see "Interrupt Detected!" on the
Receiver software instance.
Figure 38 point (1))
(
On the Receiver board the interrupt signifies that a packet has been successfully Received with a valid
CRC.
To check the source of the interrupt, click "Read Source"
Figure 38 point (2))
(
To Clear the interrupt status click "Clear All Interrupts"
Figure 38 point (3))
(
Figure 38
R e v 1 . 1
| Page 31
