Basic RF testing in SPORT Mode

1. Select the "RF Settings" Tab and set the RF parameters as required. (
2. If not already in PHY_ON enter this state by pressing CMD_PHY_ON. (
3. Select the SPORT Mode (
4. Press Update Needed. This writes the settings to BBRAM and then does a CMD_CONFIG_DEV.
( Figure 26 point (3))
5. Press CMD_PHY_RX. The part now enters PHY_RX. (
6. To exit PHY_RX press CMD_PHY_ON (
Figure 26 point (2))
Figure 26 point (5))
Figure 26
R e v 1 . 1
Figure 26 point(1))
Figure 26 point (5))
Figure 26 point (4))
