ADF7023 Evaluation Board Schematics and BOMs
Table 2 Components Common to All Daughter Boards
Qty Name
1 C1
9 C14, C16, C24, C28,
C30, C33, C37, C62,
C65
2 C15, C27
3 C23, C34, C35
1 C25
2 C26, C42
2 C39, C40
4 R3, R4, R8, R9
1 R12
1 R15
1 R16
1 Y1
1 Y2
1 U1
Table 3 Eval-ADF7023DB1Z Components (868/915MHz Separate Matches)
Qty Name
1 C2
2 C3, C5
1 C18
1 C19
1 C20
1 C66
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
Value Tolerance PCB Decal
1.5nF ±5% 0402
220nF ±10% 0402
100pF ±5% 0402
18pF ±5% 0402
150nF ±5% 0402
10uF ±20% 0603
5.6pF ±5% 0402
DNI
36k ±1% 0402
100k ±1% 0402
1.1k ±1% 0402
26MHz
32.768kHz
LFCSP-32
Value Tolerance PCB Decal
±0.25pF
1pF 0402
±0.25pF
2.2pF 0402
56pF ±5% 0402
±0.25pF
2.7pF 0402
1.2pF ±0.25pF 0402
100pF ±5% 0402
R e v 1 . 1 | Page 38
Manufacturing Part No.
GRM155R71H152KA01D
GRM155R61A224KE19D
GRM1555C1H101JZ01D
GRM1555C1H180JZ01D
GRM155R61A154KE19D
6R3R14X106MV4T
GRM1555C1H5R6DZ01D
Not inserted
MCR01MZPF3602
MCR01MZPF1003
MCR01MZPF1101
NX3225SA-26.000000MHZ-G2
ABS07-32.768KHZ-7-T
ADF7023
Manufacturing Part No.
GRM1555C1H1R0CA01D
GRM1555C1H2R2CZ01D
GRM1555C1H470JZ01D
GRM1555C1H2R7CZ01D
GRM1555C1H1R2CZ01D
GRM1555C1H101JZ01D
