3.3.13 The Calibration Menu

The Calibration Menu (see Figure 65 below) contains the calibration coefficients for the flowmeter. These values
should by changed only by properly trained personnel. The
Consult GE for help with these settings if the meter is showing erratic flow rate readings.
Run Mode
PanaFlow™ MV80 & MV82 User's Manual
ENTER
Password
ENTER
Calibration
Menu
Meter Size
or Pipe ID
Meter Factor
xxxx
Vortex Coef Ck
xx
Low Flow Cutoff
xx
Serial Number
xxxxxxxxx
Figure 65: The Calibration Menu
and
Vortex Coef Ck Low Flow Cutoff
Use
keys to access menus
Series MV80 - meter size
Series MV82 - pipe internal diameter (inches)
Meter calibration constant
Series MV80 - pulses/ft
Series MV82 - pulses/ft
Adaptive filter setting
< Vol (xxx/xxx) >
xxx
Low Flow Cutoff
Setting displayed
in volumetric flow
units (view only)
Chapter 3. Operating Instructions
are set at the factory.
3
< Mass (xxx/xxx) >
xxx
Low Flow Cutoff
Setting displayed
in mass flow
units (view only)
71
