Chapter 5. Troubleshooting and Repair
5.4.3 Symptom: No Output (cont.)
4. With the sensor still disconnected, go to the first column of the hidden diagnostics and display the vortex
shedding frequency,
electrical noise, 60 Hz for example. If all readings are correct, re-install the vortex sensor wires.
5. Verify all meter configuration and troubleshooting steps previously described. There are many possible causes
of this problem. Consult GE if necessary.
120
Figure 80: Vortex Sensor Connector Pins
. Hold a finger on the three exposed pins on the analog board. The meter should read
f
OUTSIDE
INSIDE
OUTSIDE
PanaFlow™ MV80 & MV82 User's Manual
