Chapter 2. Installation

2.3.5 Insertion Procedure for Flowmeters with Removable Insertion Tool

Refer to Figure 15 below, and follow the instructions on the next page.
26
Depth Marker Arrow
Stanchion
Scribe Mark
Removable
Insertion Tool
Flow
Figure 15: Flowmeter with Removable Insertion Tool
Upper Retractor Bracket
Stem Lock Bolt
(center)
Sensor Alignment
Pointer
Stem
Stem Clamp Nuts
Stem Clamp Bolts
Packing Gland Nuts
(covered by stem clamp)
Lower Retractor Bracket
Stem Housing
Sensor Head
