Linear Range
Smart electronics corrects for lower flow down to a Reynolds number of 5,000. The Reynolds number is calculated
using the fluid's actual temperature and pressure monitored by the meter. Rangeability depends on the fluid, process
connections and pipe size. Consult factory for your application. Velocity rangeability under ideal conditions is as
follows:
Liquids 30:1
1 foot per second velocity minimum
30 feet per second velocity maximum
Gases 30:1
10 feet per second velocity minimum
300 feet per second velocity maximum
Process Fluid Pressure
Process Connection
Flanged
Wafer
Probe Seal
Compression Fitting
Packing Gland
Packing Gland with
Removable Retractor
Packing Gland with
Permanent Retractor
PanaFlow™ MV80 & MV82 User's Manual
MV80 Pressure Ratings
Material
316L SS, A105 Carbon Steel, C276 Hastelloy
316L SS, A105 Carbon Steel, C276 Hastelloy
MV82 Pressure Ratings
Process Connection
2-inch MNPT
2-inch 150 lb flange, DN50 PN16
2-inch 300 lb flange, DN50 PN40
2-inch 600 lb flange, DN50 PN64
2-inch MNPT
2-inch 150 lb flange, DN50 PN16
2-inch 300 lb flange
2-inch MNPT
2-inch 150 lb flange, DN50 PN16
2-inch 300 lb flange
2-inch MNPT
2-inch 150 lb flange, DN50 PN16
2-inch 300 lb flange, DN50 PN40
2-inch 600 lb flange, DN50 PN64
Appendix A. Product Specifications
150, 300, 600 lb, PN16, PN40, PN64
600 lb, PN64
Material Rating
316L SS ANSI 600 lb
316L SS ANSI 150 lb,
PN16
316L SS ANSI 300 lb,
PN40
316L SS ANSI 600 lb,
PN64
316L SS 50 psig
316L SS 50 psig
316L SS 50 psig
316L SS ANSI 300 lb
316L SS ANSI 150 lb
316L SS ANSI 300 lb
316L SS ANSI 600 lb
316L SS ANSI 150 lb
316L SS ANSI 300 lb
316L SS ANSI 600 lb
Rating
Ordering Code
CNPT
C150, C16
C300, C40
C600, C64
PNPT
P150, P16
P300, P40
PM, RR
P150, P16, RR
P300, P40, RR
PNPTR
P150R, P16R
P300R, P40R
P600R, P64R
