Chapter 3. Operating Instructions

3.3.6 The Totalizer #1 Menu

Use the Totalizer Menu to configure and monitor the totalizer. The totalizer output is a 50 millisecond (.05 second)
positive pulse (relay closed for 50 milliseconds). The totalizer cannot operate faster than one pulse every
100 millisecond (.1 second). A good rule to follow is to set the unit per pulse value equal to the maximum flow in the
same units per second. This will limit the pulse to no faster than one pulse every second.
As an example of how to set an output, refer to Figure 58 on page 61. This example shows how to set the totalizer to
track mass flow in kg/sec.
Note: All outputs are disabled while using the Setup Menus.
First, set the desired units of measurement:
1. Use keys to move to the Units Menu (see to "The Units Menu" on page 67).
key until Mass Flow Unit appears. Press ENTER.
2. Press the
3. Press the key until kg appears in the numerator. Press the
denominator. Press the
4. Press the key until Units Menu appears.
Second, set the pulse output:
1. Use keys to move to the Totalizer Menu.
2. Press the key until Totaling appears.
3. Press ENTER and press the
key to set the pulse output in the units you have selected for mass flow of kg/sec. Press ENTER and
4. Press the
use keys to set the pulse value equal to the maximum flow in the same units per second. Press
ENTER.
5. To reset the totalizer, press the
totalizer if desired. Press ENTER.
6. Press the EXIT key and answer YES to permanently save your changes.
60
key until sec appears in the denominator. Press ENTER to select.
key to select Mass. Press ENTER.
key until Reset Total? appears. Press ENTER and the
key to move the underline cursor to the
PanaFlow™ MV80 & MV82 User's Manual
key to reset the
