3.3.8 The Energy Menu for EMS Energy Meters Only

There are several possibilities regarding the measurement of water or steam energy, given the location of the meter and
the use of a second RTD. Table 3 below summarizes the possibilities:
Fluid
Water
Water
Water
Steam
Steam
To use the above options, you must properly configure the meter in the Energy Menu (see Figure 60 on page 64) by
completing these steps:
1. Loc in Sent Flow?
2.
Heating System?
for cooling. Always select
3. Select a
% Returned.
100%, or can be less than 100% if historical data shows the amount of makeup water used. If a second RTD is
not used, set to 0%. When 0% is selected, the energy calculation represents the outgoing energy only (no return
energy is subtracted).
Note: The meter ships from the factory assuming 0% return and has a 1000 ohm resistor installed in the RTD #2
wiring location. This needs to be removed if the meter is to be used in a manner other than with 0% return and
with the customer-supplied RTD in its place.
PanaFlow™ MV80 & MV82 User's Manual
Table 3: Configuration Options
Meter Location
"Sent" Flow Line
"Return" Flow Line
"Sent" Flow Line
"Sent" Flow Line
"Sent" Flow Line
Select Yes or No based on where the meter is located. Refer to Table 3 above.
Select for a hot water system used for heating. Select
Yes
Yes for a steam system.
number between 0% and 100%
Second RTD
"Return" Flow Line
"Sent" Flow Line
None
"Return" Flow Line (condensate)
None
. Estimate the amount of water that returns. It is usually
Chapter 3. Operating Instructions
Measurement
Change in Energy
Change in Energy
Outgoing Energy
Change in Energy
Outgoing Energy
for a chilled water system used
No
