Chapter 2. Installation
2.1 Installation Overview
PanaFlow Vortex Flowmeter installations are simple and straightforward. Both the Series MV80 In-Line and Series
MV82 Insertion type flowmeter installations are covered in this chapter. After reviewing the installation requirements
given below, see page 11 for Series MV80 installation instructions. See "Series MV82 Insertion Flowmeter
Installation" on page 15 for Series MV82 installation instructions. Wiring instructions begin in "Loop Power
Flowmeter Wiring Connections" on page 32.
2.1.1 Flowmeter Installation Requirements
WARNING!
hazardous location installation.
Before installing the flowmeter, verify that the installation site allows for these considerations:
1. Line pressure and temperature will not exceed the flowmeter rating.
2. The location meets the required minimum number of pipe diameters upstream and downstream of the sensor
head as illustrated in Figure 4 on page 10.
3. Safe and convenient access with adequate overhead clearance for maintenance purposes.
4. Verify that the cable entry into the instrument meets the specific standard required for hazardous area
installations.
5. For remote installations, verify the supplied cable length is sufficient to connect the flowmeter sensor to the
remote electronics.
Also, before installation, check your flow system for anomalies such as:
•
Leaks
•
Valves or restrictions in the flow path which could create disturbances in the flow profile that might cause
unexpected flow rate indications
PanaFlow™ MV80 & MV82 User's Manual
Consult the flowmeter nameplate for specific flowmeter approvals before any
Chapter 2. Installation
9
