Application Examples; Introduction - Danfoss VLT AutomationDrive FC 302 Installation Manual

Application Examples

6 Application Examples

6.1 Introduction

The examples in this section are intended as a quick
reference for common applications.
•
Parameter settings are the regional default values
unless otherwise indicated (selected in
parameter 0-03 Regional Settings).
•
Parameters associated with the terminals and
their settings are shown next to the drawings.
•
Required switch settings for analog terminals A53
or A54 are also shown.
NOTICE!
When using the optional STO feature, a jumper wire may
be required between terminal 12 (or 13) and terminal 37
for the frequency converter to operate with factory
default programming values.
NOTICE!
The following examples refer only to the frequency
converter control card (right LCP), not the filter.
6.2 Application Examples
CAUTION
Thermistors must use reinforced or double insulation to
meet PELV insulation requirements.
MG37A322
Installation Manual
FC
+24 V
+24 V
D IN
D IN
COM
D IN
D IN
D IN
D IN
D IN
+10 V
A IN
A IN
COM
A OUT
COM
Table 6.1 AMA with T27 Connected
FC
+24 V
+24 V
D IN
D IN
COM
D IN
D IN
D IN
D IN
D IN
+10 V
A IN
A IN
COM
A OUT
COM
Table 6.2 AMA without T27 Connected
