Introduction
1 Control card
2 Control input terminals
3 Local control panel (LCP)
4 Control card C option
5 Mounting bracket
6 Power card mounting plate
7 Power card
8 IGBT gate drive card
9 Upper capacitor bank assembly
10 Soft-charge fuses
11 DC inductor
12 Fan transformer
13 IGBT module
Figure 1.4 Frame Size E9 Drive Enclosure
MG37A322
Installation Manual
25
24
23
22
21
20
17
18
19
14
15
16
17
18
19
20
21
22
23
24
25
Danfoss A/S © Rev. 04/2015 All rights reserved.
8
9
11
10
12
13
14
15
16
SCR and diode
Fan inductor (not on all units)
Soft-charge resistor assembly
IGBT output bus bar
Fan assembly
Output motor terminals
Current sensor
Main AC power input terminals
Input terminal mounting plate
AC input bus bar
Soft-charge card
Lower capacitor bank assembly
1 1
