Appendix A - Parameters
9.3.8 AF Settings 300-**
NOTICE!
Except for parameter 300-10 Active Filter Nominal Voltage, it is not recommended to change the settings in this par.
group for the Low Harmonic Drive
Par. No. # Parameter description
300-0* General Settings
300-00 Harmonic Cancellation Mode
300-01 Compensation Priority
300-1* Network Settings
300-10 Active Filter Nominal Voltage
300-2* CT Settings
300-20 CT Primary Rating
300-22 CT Nominal Voltage
300-24 CT Sequence
300-25 CT Polarity
300-26 CT Placement
300-29 Start Auto CT Detection
9 9
300-3* Compensation
300-30 Compensation Points
300-35 Cos-phi Reference
300-4* Paralleling
300-40 Master Follower Selection
300-41 Follower ID
300-42 Num. of Follower AFs
300-5* Sleep Mode
300-50 Enable Sleep Mode
300-51 Sleep Mode Trig Source
300-52 Sleep Mode Wake-up Trigger
300-53 Sleep Mode Sleep Trigger
118
®
VLT AutomationDrive FC 302 Low Harmonic Drive
132–630 kW
Default value
[0] Overall
[0] Harmonics
ExpressionLimit
ExpressionLimit
342 V
[0] L1, L2, L3
[0] Normal
[1] Load Current
[0] Off
0.0 A
0.500 N/A
[2] Not Paralleled
1 N/A
1 N/A
null
[0] Line power
ExpressionLimit
80%
