Application examples
Pump reservoir
Modulating control of injection makes for a more stable liquid
level and suction pressure.
Separator on flooded evaporator
Modulating control and the valve's large capacity range ensure a
stable level - even under conditions of quickly changing loads.
Intermediate cooler
The level transmitter's wide measuring range enables it to monitor
the liquid at all levels of the reservoir - and hence to use the signal
for safety functions in connection with the max. permissible level
Receiver / condenser
The control system's short reaction time makes it very suited for
high-pressure float systems with small refrigerant charges.
EKC 347
Manual RS8AX702 DKRCC.ES.R1.A1.02/ 520H4020 © Danfoss 01-2011
3
