Introduction
1 1
1 Local control panel (LCP)
2 Active filter card (AFC)
3 Soft-charge resistors
4 Metal oxide varistor (MOV)
5 AC capacitors discharge board
6 LC inductor
7 HI inductor
8 Mixing fan
9 IGBT fuses
Figure 1.7 Frame Size F18 Filter Cabinet
12
®
VLT AutomationDrive FC 302 Low Harmonic Drive
132–630 kW
1
2
18
17
16
15
14
12
Danfoss A/S © Rev. 04/2015 All rights reserved.
3
4
13
10 Line power bus bars to drive input
11 Heatsink fans
12 Line power terminals (R/L1, S/L2, T/L3) from options cabinet
13 RFI differential mode filter
14 RFI common mode filter
15 Line power contactor
16 Power card
17 Control card
18 LCP cradle
5
6
7
8
9
10
11
