Manually reset the frequency converter or active
filter after a fault when auto-reset is inactive.
NOTICE!
For commissioning via PC, install the MCT 10 Set-up
Software. The software is available for download (basic
version) or for ordering (advanced version, order number
130B1000). For more information and downloads, see
www.danfoss.com/BusinessAreas/DrivesSolutions/Software
+MCT10/MCT10+Downloads.htm.
5 5

5.3.2 LCP Layout

The LCP is divided into 4 functional groups (see Figure 5.1).
A. Display area
B. Display menu keys
C. Navigation keys and indicator lights (LEDs)
D. Operation keys and reset
1
2
A
4
6
B
7
10 C
On
15
16
17
D
18
Figure 5.1 Local Control Panel (LCP)
A. Display area
The display area is activated when the frequency converter
receives power from mains voltage, a DC bus terminal, or
an external 24 V DC supply.
54
Status
0.0 % 0.00 A 0.00 kW
0.0Hz
2605 kWh
O Remote Stop
Quick Main Alarm
Status
Menu Menu
OK
Warn.
Alarm
Hand Auto
Reset
O
on on
19 20
Danfoss A/S © Rev. 04/2015 All rights reserved.
®
VLT AutomationDrive FC 302 Low Harmonic Drive
132–630 kW
The information displayed on the LCP can be customised
for user application. Select options in the Quick Menu
Q3-13 Display Settings.
Callout
1
2
3
4
5
Table 5.2 Legend to Figure 5.1, Display Area
(Frequency Converter Side)
B. Display menu keys
Menu keys are used for menu access for parameter set-up,
toggling through status display modes during normal
operation, and viewing fault log data.
Callout
6
7
3
1(1)
8
5
9
Table 5.3 Legend to Figure 5.1, Display Menu Keys
9
Log
C. Navigation keys and indicator lights (LEDs)
Navigation keys are used for programming functions and
moving the display cursor. The navigation keys also
8
provide speed control in local (hand) operation. There are
11
also 3 frequency converter status indicator lights in this
area.
12
Callout
10
13
11
14
12
21
13
14
Table 5.4 Legend to Figure 5.1, Navigation Keys
Display Parameter number
1.1 0-20
1.2 0-21
1.3 0-22
2 0-23
3 0-24
Key Function
Status Shows operational information.
Quick Menu Allows access to programming
parameters for initial set-up instructions
and many detailed application
instructions.
Main Menu Allows access to all programming
parameters.
Alarm Log Displays a list of current warnings, the
last 10 alarms, and the maintenance log.
Key Function
Back Reverts to the previous step or list in the
menu structure.
Cancel Cancels the last change or command as
long as the display mode has not
changed.
Info Press for a definition of the function being
displayed.
Navigation Press to move between items in the menu.
keys
OK Press to access parameter groups or to
enable an option.
Default setting
Reference %
Motor current
Power [kW]
Frequency
kWh counter
